FIXAR EDUTraining Package
FIXAR EDU will teach you how to design, configure and operate unmanned airplane systems! This is a unique complex with an aerial device for training in the operation of unmanned aerial systems (UAS).
​FIXAR EDU is a small copy of the FIXAR 007 flagship model and has two flight modes: copter and airplane. This allows you to gain piloting skills for multi-rotor and airplane-type devices. During the operation of this device, you can study not only the stable flight of the multi-rotor system but also aerodynamics, wing lift, as well as a combination of operating skills of both aerodynamic patterns to achieve better results.
Course Profile
​
Learning Plans
Training Materials
​
Video Lessons
What You Get
-
Study aerodynamics and wing lift on FIXAR EDU example
-
Find out all piloting features of airplane-type unmanned aircraft
-
​With 3D-printed elements in the aircraft structure, you can contrive, draw, print and substitute your own elements instead of the pre-fabricated parts and then see by trial how it will influence the flying performance, strength, maintainability and safety of the aircraft
-
​Develop thinking outside the box and think what extra capabilities can be implemented aboard such aircraft
FIXAR EDUTechnical Specification
BASE STRUCTURE MATERIAL
PLA or PETG
WING SPAN
380 mm (15 in)
MAXIMUM SPEED
up to 50 km/h (31 mph)
CRUISING SPEED
30 km/h (18.6 mph)
CLIMB RATE
15 km/h (9.3 mph)
IN-FLIGHT TIME
8 min
WIND RESISTANCE IN VERTICAL FLIGHT
8 m/s (17.9 mph)
OPERATING TEMPERATURE
30 to +60 °Ð¡ (-22 °F to 140 °F)
CASE DIMENSIONS
50 x 30 x 20 cm (19.6 x 11.8 x 7.8 in)
CASE WEIGHT WITH EQUIPMENT
1 kg (2.2 lbs)
